Main performance indicators
Zero-bias stability : ≤0.007°/h（100s，1σ)
Zero bias repeatability : ≤0.010°/h
Variable temperature stability : ≤0.02°/h（100s，1σ,0.3℃/min）
Scale factor non-linearity : ≤5ppm
Full temperature scale repeatability : ≤30ppm（1σ)
Dynamic range : ±400°/s
Random wandering : ≤0.001°/√h
Physical characteristics
Dimensions
Table headerΦ76mm×15.8mm
Electronic box 120mm×105mm×26mm
Weight :
Table header：140g×3
Electronic box：250g
Product interface
Power supply requirements : ±5V
Output form: RS422output
Environmental adaptabilit
Operating temperature : -45℃-+75℃
Storage temperature : -55℃-+85℃
Impact resistant: 15g
Resistant to random vibrations : 6.8g
Product features
Features : The product adopts a three-axis one-piece structure with magnetic shielding protection
Application field : High-performance navigation and positioning orientation
